Chapter 6. The Central Nervous System

6.6 The Spinal Cord

Learning Objectives

By the end of this section, you will be able to:

  • describe the regions of the spinal cord.

The description of the central nervous system is concentrated on the structures of the brain, but the spinal cord is another major organ of the system. Whereas the brain develops out of expansions of the neural tube into primary and then secondary vesicles, the spinal cord maintains the tube structure and is only specialized into certain regions. As the spinal cord continues to develop in the newborn, anatomical features mark its surface. Axons enter the posterior side through the dorsal (posterior) nerve root. The axons emerging from the anterior side do so through the ventral (anterior) nerve root. Note that it is common to see the terms dorsal (dorsal meaning “back”) and ventral (ventral meaning “belly”) used interchangeably with posterior and anterior, particularly in reference to nerves and the structures of the spinal cord. You should learn to be comfortable with both.

On the whole, the posterior regions are responsible for sensory functions and the anterior regions are associated with motor functions. The length of the spinal cord is divided into regions that correspond to the regions of the vertebral column. The name of a spinal cord region corresponds to the level at which spinal nerves pass through the intervertebral foramina. Immediately adjacent to the brain stem is the cervical region, followed by the thoracic, then the lumbar, and finally the sacral region. The spinal cord is not the full length of the vertebral column because the spinal cord does not grow significantly longer after the first or second year, but the skeleton continues to grow.

Gray Horns

In cross-section, the gray matter of the spinal cord has the appearance of an ink-blot test, with the spread of the gray matter on one side replicated on the other—a shape reminiscent of a bulbous capital “H.” As shown in Figure 6.6.1, the gray matter is subdivided into regions that are referred to as horns. The posterior horn is responsible for sensory processing. The anterior horn sends out motor signals to the skeletal muscles. The lateral horn, which is only found in the thoracic, upper lumbar, and sacral regions, is the central component of the sympathetic division of the autonomic nervous system.

Some of the largest neurons of the spinal cord are the multipolar motor neurons in the anterior horn. The fibers that cause contraction of skeletal muscles are the axons of these neurons. The motor neuron that causes contraction of the big toe, for example, is located in the sacral spinal cord. The axon that has to reach all the way to the belly of that muscle may be a meter in length. The neuronal cell body that maintains that long fiber must be quite large, possibly several hundred micrometers in diameter, making it one of the largest cells in the body.

This figure shows the cross section of the spinal cord. The top panel shows a diagram of the cross section and the major parts are labeled. The bottom panel shows an ultrasound image of the spinal cord cross section.
Figure 6.6.1 – Cross-Section of Spinal Cord: The cross-section of a thoracic spinal cord segment shows the posterior, anterior, and lateral horns of gray matter, as well as the posterior, anterior, and lateral columns of white matter (LM × 40). (credit: Micrograph provided by the Regents of University of Michigan Medical School © 2012)

White Columns

Just as the gray matter is separated into horns, the white matter of the spinal cord is separated into columns. Ascending tracts of nervous system fibers in these columns carry sensory information up to the brain, whereas descending tracts carry motor commands from the brain. Looking at the spinal cord longitudinally, the columns extend along its length as continuous bands of white matter. Between the two posterior horns of gray matter are the posterior columns. Between the two anterior horns, and bounded by the axons of motor neurons emerging from that gray matter area, are the anterior columns. The white matter on either side of the spinal cord, between the posterior horn and the axons of the anterior horn neurons, are the lateral columns. The posterior columns are composed of axons of ascending tracts. The anterior and lateral columns are composed of many different groups of axons of both ascending and descending tracts—the latter carrying motor commands down from the brain to the spinal cord to control output to the periphery.

Section Review

The central nervous system consists of the brain and the spinal cord. Broadly, the posterior regions are responsible for sensory functions and the anterior regions are associated with motor functions. Axons enter the posterior side of the spinal cord through the dorsal nerve root. The axons emerging from the anterior side do so through the ventral nerve root. The spinal cord is divided into the cervical, thoracic, lumbar, and sacral regions. In a cross-section of the spinal cord, the gray matter is seen on the inside shaped like a capital “H,” surrounded by white matter. The gray matter is also known as the gray horns and consists of the posterior, anterior, and lateral horns. The posterior horn is responsible for sensory processing. The anterior horn sends out motor signals to the skeletal muscles. The lateral horn is the central component of the sympathetic division of the autonomic nervous system.

The white matter is separated into columns: the posterior, anterior, and lateral columns. The posterior columns are composed of axons of ascending tracts. The anterior and lateral columns are composed of both ascending and descending tracts—the latter carrying motor commands down from the brain to the spinal cord to control output to the periphery.

Review Questions

Glossary

anterior column
white matter between the anterior horns of the spinal cord composed of many different groups of axons of both ascending and descending tracts
anterior horn
gray matter of the spinal cord containing multipolar motor neurons, sometimes referred to as the ventral horn
ascending tract
central nervous system fibers carrying sensory information from the spinal cord or periphery to the brain
descending tract
central nervous system fibers carrying motor commands from the brain to the spinal cord or periphery
dorsal (posterior) nerve root
axons entering the posterior horn of the spinal cord
lateral column
white matter of the spinal cord between the posterior horn on one side and the axons from the anterior horn on the same side; composed of many different groups of axons, of both ascending and descending tracts, carrying motor commands to and from the brain
lateral horn
region of the spinal cord gray matter in the thoracic, upper lumbar, and sacral regions that is the central component of the sympathetic division of the autonomic nervous system
posterior columns
white matter of the spinal cord that lies between the posterior horns of the gray matter, sometimes referred to as the dorsal column; composed of axons of ascending tracts that carry sensory information up to the brain
posterior horn
gray matter region of the spinal cord in which sensory input arrives, sometimes referred to as the dorsal horn
ventral (anterior) nerve root
axons emerging from the anterior or lateral horns of the spinal cord
